7/8" Corrugated
Designed for commercial, industrial, residential, and steel-framed building applications, the 7/8 Corrugated Panel provides architects and designers a corrugated profile option which can be installed as both a roof and a wall panel. The 7/8 corrugation height creates the structural integrity required to allow installation over a solid substrate or open framing.
Exposed fastener panel for roof and wall applications.
3:12 minimum recommended roof pitch.
Suitable for solid deck or open framing.
Rib Height: 3/4".
Coverage: 36" Coverage
22, 24 and 26 gauge high strength steel.
Anti-corrosion AZ50 Galvalume coating for painted and AZ55 for unpainted steel.
26 ga available in Siliconized Modified Polyester Paint Systems View Warranty
24 and 22 ga available in PVDF (Kynar 500 or Hylar 5000) Paint System
