FL100
FL100 is a versatile panel that can be used on commercial and residential applications. The panel can be installed in a soffit application or vertically as a wall panel. Venting is available when used as a soffit panel. The interlocking mechanism allows for rapid installation and provides a flush appearance.
Specifications:
Application: Wall Panel
Fastener: Concealed Fastener
Suitable for solid substrate or open framing.
Rib Height: 1".
Coverage: 12" Coverage
Soffit and wall panel
High Strength Steel Gauge Options: 24 GA, 26 GA
0.032" aluminum.
Anti-corrosion AZ50 Galvalume coating for painted and AZ55 for unpainted steel.
24 ga and aluminum available in PVDF (Kynar 500 or Hylar 5000) Paint System.
